2711R-T10T 2711RT10T อัลเลนแบรดลีย์ AB พาเนลวิว 800 10.4 นิ้วเทอร์มินัล HMI
⇒คลิกที่นี่เพื่อราคาดี 2711R-T10T
ยี่ห้อ / ผู้ผลิต | อัลเลนแบรดลีย์ / USA |
ส่วนจำนวน |
2711R-T10T |
หมายเลขชิ้นส่วนอื่น | 2711R-T10T |
ลักษณะ | เซอร์โวมอเตอร์ |
Dimennsions |
38.5x31x16cm |
น้ำหนัก | 2.42 กก |
รายละเอียดสินค้า
The AB 2711R-T10T PanelView 800 HMI Terminal is an operator interface with the Windows CE 6.0 operating system which allows users to graphically view the machine status and to monitor and manage machine functions. AB 2711R-T10T PanelView 800 HMI Terminal เป็นอินเทอร์เฟซผู้ใช้งานที่มีระบบปฏิบัติการ Windows CE 6.0 ซึ่งช่วยให้ผู้ใช้สามารถดูสถานะของเครื่องแบบกราฟิกและตรวจสอบและจัดการฟังก์ชั่นเครื่อง Users can input and set the machine's parameters through the 65K color trans-missive, thin-film transistor color active matrix, 10-inch LCD screen with a display dimension of 8.31in x 6.24in and a resolution of 800 x 600 pixel. ผู้ใช้สามารถป้อนและตั้งค่าพารามิเตอร์ของเครื่องผ่านเมทริกซ์แอคทีฟสีทรานซิสเตอร์มิสไซล์ทรานส์มิสซูรี่สี 65K หน้าจอ LCD ขนาด 10 นิ้วที่มีขนาดจอแสดงผล 8.31in x 6.24 นิ้วและความละเอียด 800 x 600 พิกเซล The 2711R-T10T has an analog resistive surface touch and a LED backlight with a standby time of up to 40,000 hours. 2711R-T10T มีการสัมผัสพื้นผิวตัวต้านทานแบบอะนาล็อกและแสงไฟ LED พร้อมเวลาสแตนด์บายสูงสุด 40,000 ชั่วโมง It has a battery-backed real-time clock with a battery lifespan of 5 years when used at a temperature below 77 °F. มีนาฬิกาแบบเรียลไทม์ที่รองรับแบตเตอรี่พร้อมอายุการใช้งานแบตเตอรี่ 5 ปีเมื่อใช้ที่อุณหภูมิต่ำกว่า 77 ° F It also has a factory-built internal cache memory of 256 MB for storing the user settings and application parameters. นอกจากนี้ยังมีหน่วยความจำแคชภายในที่สร้างขึ้นจากโรงงานขนาด 256 MB สำหรับจัดเก็บการตั้งค่าผู้ใช้และพารามิเตอร์แอปพลิเคชัน
The 2711R-T10T is also fitted with a 256-MB Synchronous DRAM for application processes with a processor speed of 800MHz and it is compatible with MicroLogix and Micro 800 Controllers. 2711R-T10T นั้นมาพร้อมกับ DRAM ซิงโครนัส 256 เมกะไบต์สำหรับกระบวนการแอปพลิเคชันด้วยความเร็วโปรเซสเซอร์ 800MHz และเข้ากันได้กับ MicroLogix และ Micro 800 Controllers The 2711R-T10T uses the isolated RS-232 and RS-422/RS-485 serial communication ports for data transmission and for programming by a PC using the Connected Components Workbench Software version 8.0 or later, which is compatible with Microsoft Windows 8.0 and 8.1. 2711R-T10T ใช้พอร์ตสื่อสารแบบอนุกรม RS-232 และ RS-422 / RS-485 แยกต่างหากสำหรับการส่งข้อมูลและการเขียนโปรแกรมโดยพีซีโดยใช้ซอฟต์แวร์คอมโพเนนต์การเชื่อมต่อที่เชื่อมต่อเวอร์ชัน 8.0 หรือใหม่กว่าซึ่งเข้ากันได้กับ Microsoft Windows 8.0 และ 8.1 . It also supports a USB 2.0 host port for connection to external peripheral devices and a micro SD card slot for an external memory of up to 32 GB. นอกจากนี้ยังรองรับพอร์ตโฮสต์ USB 2.0 สำหรับเชื่อมต่อกับอุปกรณ์ต่อพ่วงภายนอกและช่องเสียบการ์ด micro SD สำหรับหน่วยความจำภายนอกสูงสุด 32 GB The 2711R-T10T has dimensions of 8.9 x 11.3 x 2.2 in and it weighs approximately 10lb. 2711R-T10T มีขนาด 8.9 x 11.3 x 2.2 นิ้วและมีน้ำหนักประมาณ 10lb It is designated with the T4 temperature code and has a functional temperature of 0-50 °C (32-122 °F) with a NEMA/UL Type 4X, 12, 13, and IP65 enclosure type rating and a front bezel protection feature. มันถูกกำหนดด้วยรหัสอุณหภูมิ T4 และมีอุณหภูมิในการทำงาน 0-50 ° C (32-122 ° F) พร้อมกับประเภทตู้ NEMA / UL ประเภท 4X, 12, 13, และ IP65 และคุณลักษณะการป้องกันขอบด้านหน้า
บริการของเรา
เต็ม 100% ใหม่ - ตราโรงงานเดิม
รับประกัน: 12 เดือน
แพคเกจ: บรรจุเดิมด้วยกล่อง
เวลาการส่งมอบ: จัดส่งใน 3 วันหลังจากการชำระเงิน
