สถานที่กำเนิด | สหรัฐอเมริกา |
ชื่อแบรนด์ | AB |
ได้รับการรับรอง | CO.CQ |
หมายเลขรุ่น | 1756-M22 |
1756-M22 1756M22 Allen Bradley ControlLogix Logix5555 โมดูลหน่วยความจำแบบไม่ลบเลือน
⇒คลิกที่นี่เพื่อราคาดี 1756-M22
ยี่ห้อ / ผู้ผลิต | อัลเลนแบรดลีย์ / USA |
ส่วนจำนวน |
1756-M22 |
หมายเลขชิ้นส่วนอื่น | 1756-M22 |
ลักษณะ | เซอร์โวมอเตอร์ |
Dimennsions |
18x12.6x12cm |
น้ำหนัก | 0.7 กก |
รายละเอียดสินค้า
The AB 1756-M22 module is a 750 KB non-volatile memory module for AB ControlLogix 5555 controllers. โมดูล AB 1756-M22 เป็นโมดูลหน่วยความจำแบบไม่ลบเลือน 750 KB สำหรับคอนโทรลเลอร์ AB ControlLogix 5555 ControlLogix controllers with which the 1756-M22 module is compatible include the 1756-L55, 1756-L55M12, 1756-L55M13, 1756-L55M14, 1756-L55M16, 1756-L55M22, 1756-L55M23, and the 1756-L55M24 controllers. คอนโทรลเลอร์ LogLogix ที่ใช้กับโมดูล 1756-M22 นั้นรวมถึงคอนโทรลเลอร์ 1756-L55, 1756-L55M12, 1756-L55M13, 1756-L55M14, 1756-L55M16, 1756-L55M23, 1756-L55M23, Firmware version 10.x or later is required to be used on the controllers for them to work with the 1756-M22 memory module. จำเป็นต้องใช้เฟิร์มแวร์เวอร์ชั่น 10.x หรือใหม่กว่าบนตัวควบคุมเพื่อให้สามารถทำงานกับโมดูลหน่วยความจำ 1756-M22 If the controllers have an older firmware version, the controller firmware must be upgraded prior to memory module installation. หากคอนโทรลเลอร์มีเฟิร์มแวร์เวอร์ชั่นเก่ากว่าต้องอัพเกรดเฟิร์มแวร์คอนโทรลเลอร์ก่อนการติดตั้งโมดูลหน่วยความจำ To prevent damage to the memory module, the battery must be disconnected from the controller before installing or replacing the memory module. เพื่อป้องกันความเสียหายที่เกิดขึ้นกับโมดูลหน่วยความจำต้องถอดแบตเตอรี่ออกจากคอนโทรลเลอร์ก่อนทำการติดตั้งหรือเปลี่ยนโมดูลหน่วยความจำ The installation or replacement of the 1756-M22 module on the ControlLogix 5555 controller requires the following 4 steps: removing the side plate of the controller, removing the existing memory board, installing the new memory board, and replacing the controller side plate. การติดตั้งหรือเปลี่ยนโมดูล 1756-M22 บนตัวควบคุม ControlLogix 5555 ต้องใช้ 4 ขั้นตอนดังต่อไปนี้: การถอดแผ่นด้านข้างของตัวควบคุมการถอดบอร์ดหน่วยความจำที่มีอยู่การติดตั้งบอร์ดหน่วยความจำใหม่และการเปลี่ยนแผ่นด้านข้างตัวควบคุม Labels can be placed on the side of the controller to identify the type of memory board that is installed. สามารถติดป้ายกำกับไว้ที่ด้านข้างของคอนโทรลเลอร์เพื่อระบุประเภทของหน่วยความจำที่ติดตั้ง
The 1756-M22 module is sensitive to ESD. โมดูล 1756-M22 มีความไวต่อ ESD The following precautions need to be followed to prevent damage to the module: touching a grounded object to discharge static, wearing a grounded wrist strap, avoiding touching the connector or module components, using static-safe workstations, and storing the module in static-safe containers. ข้อควรระวังต่อไปนี้จะต้องปฏิบัติตามเพื่อป้องกันความเสียหายต่อโมดูล: การสัมผัสวัตถุที่มีสายกราวด์เพื่อคายประจุไฟฟ้าสถิต, การสวมใส่สายรัดข้อมือที่มีสายกราวด์, หลีกเลี่ยงการสัมผัสตัวเชื่อมต่อหรือส่วนประกอบโมดูลโดยใช้เวิร์กสเตชัน ตู้คอนเทนเนอร์ The operating temperature range for the 1756-M22 module is from 0 to 60 degrees Celsius. ช่วงอุณหภูมิการทำงานสำหรับโมดูล 1756-M22 อยู่ระหว่าง 0 ถึง 60 องศาเซลเซียส The storage temperature range for the module is from -40 to 85 degrees Celsius. ช่วงอุณหภูมิการเก็บรักษาของโมดูลอยู่ระหว่าง -40 ถึง 85 องศาเซลเซียส The range for the relative humidity is from 5 to 95% (non-condensing). ช่วงสำหรับความชื้นสัมพัทธ์อยู่ระหว่าง 5 ถึง 95% (ไม่มีการควบแน่น) The operating and non-operating shock ratings for the module are 30 G and 50 G, respectively. การจัดอันดับการทำงานและการไม่ได้ทำงานของโมดูลคือ 30 G และ 50 G ตามลำดับ The enclosure of the module is open and it complies with the T4 North American temperature code and the T4 IEC temperature code. กล่องหุ้มของโมดูลเปิดอยู่และสอดคล้องกับรหัสอุณหภูมิ T4 ในอเมริกาเหนือและรหัสอุณหภูมิ T4 IEC
บริการของเรา
เต็ม 100% ใหม่ - ตราโรงงานเดิม
รับประกัน: 12 เดือน
แพคเกจ: บรรจุเดิมด้วยกล่อง
เวลาการส่งมอบ: จัดส่งใน 3 วันหลังจากการชำระเงิน
